Gear Trains & Power Transmission Lab
Explore how gears trade speed for torque and vice versa. Build simple pairs, multi-stage compound trains, and belt drives. See how power is conserved while RPM and torque change through each stage.
Guided Experiment: Speed-Torque Trade-off
How does changing the gear ratio affect output speed and torque? Is power conserved across different gear configurations?
Write your hypothesis in the Lab Report panel, then click Next.
Gear Train Diagram
Controls
Results
Odd number of gear meshings reverses the output direction.
Data Table
(0 rows)| # | Configuration | Input RPM | Gear Ratio | Output RPM | Output Torque (N·m) | Direction |
|---|
Reference Guide
Gear Ratio Basics
The gear ratio is the ratio of teeth on the driven gear to teeth on the driver gear. A ratio greater than 1 means speed reduction and torque multiplication.
A 40-tooth gear driven by a 20-tooth gear produces a 2:1 ratio, halving the speed while doubling the torque.
Compound Gear Trains
In a compound gear train, the overall ratio is the product of each stage's individual ratio. This allows extreme ratios with reasonably sized gears.
Each meshing pair reverses the rotation direction. Odd stages produce opposite rotation; even stages restore the original direction.
Torque & Power
Power equals torque times angular velocity. In an ideal (frictionless) gear train, power is conserved. As speed decreases, torque increases proportionally.
This is why low gears on a bicycle feel easier to pedal uphill but spin the wheel slowly.
Belt Drives
Belt drives transmit power between pulleys using a flexible belt. The ratio depends on pulley diameters instead of teeth, but the math is the same.
Unlike meshing gears, belt drives do not reverse rotation direction. Both pulleys spin the same way.
